Hey guys! Today, we're diving into how to install Security Onion on Ubuntu. Security Onion is a fantastic, free, and open-source Linux distribution for threat hunting, enterprise security monitoring, and log management. If you're looking to level up your cybersecurity game, you're in the right place. This guide will walk you through each step, ensuring you have a robust security monitoring system up and running. Let's get started!

Prerequisites

Before we jump into the installation, let’s make sure you have everything you need. This part is crucial because skipping it might lead to headaches later on. Trust me, been there, done that!

• A fresh Ubuntu Server installation: It's best to start with a clean slate to avoid any conflicts or compatibility issues. I recommend using the latest LTS (Long Term Support) version. As of now, Ubuntu 20.04 LTS or 22.04 LTS are great choices.
• Sufficient hardware resources: Security Onion can be resource-intensive, especially when dealing with a lot of network traffic. Here’s a general guideline:
  • CPU: At least 4 cores.
  • RAM: Minimum 16 GB, but 32 GB is highly recommended.
  • Storage: At least 200 GB. SSD is preferable for better performance.
• Network Interface: Ensure you have at least two network interfaces.
  • One interface will be used for management (connecting to the internet, SSH, etc.).
  • The other interface will be used for monitoring network traffic. This interface should be in promiscuous mode to capture all traffic.
• Internet Connection: You'll need internet access to download the Security Onion packages and updates.
• Basic Linux Knowledge: Familiarity with the command line will be helpful.

Make sure your Ubuntu server is up-to-date before proceeding. Run these commands:

sudo apt update
sudo apt upgrade -y

This will ensure you have the latest packages and security patches.

Downloading Security Onion

Alright, with the prerequisites out of the way, let’s download Security Onion. Head over to the official Security Onion website (https://securityonion.net/) and grab the latest ISO image. Alternatively, you can use wget directly on your Ubuntu server. First, navigate to your home directory, then download the ISO:

cd ~
wget https://securityonion.net/download/securityonion-2.4.0-20231027.iso

Note: The link provided is an example. Ensure you replace it with the latest version available on the Security Onion website.

Once the download is complete, you might want to verify the integrity of the ISO image. You can do this by checking the SHA256 checksum. Security Onion provides these checksums on their download page.

sha256sum securityonion-2.4.0-20231027.iso

Compare the output with the SHA256 checksum provided on the Security Onion website. If they match, you're good to go!

Installing Security Onion

Now comes the exciting part – installing Security Onion! You have a couple of options here:

1. Direct Installation: If you're installing on a physical server, you can burn the ISO image to a USB drive and boot from it.
2. Virtual Machine: If you're using a virtual machine (like VMware or VirtualBox), you can mount the ISO image to the VM.

I'll assume you know how to boot from a USB drive or mount an ISO in your VM. Once you’ve booted from the Security Onion ISO, you’ll be greeted with the Security Onion installer.

Follow these steps:

1. Boot from the ISO: Select the boot option that corresponds to booting from the ISO image.
2. Graphical Installer: The Security Onion installer will start in a graphical environment. Click "Install Security Onion" to begin.
3. Language and Keyboard: Choose your preferred language and keyboard layout.
4. Installation Type: Select "Erase disk and install Security Onion." This will format the entire disk, so make sure you've backed up any important data.
5. Time Zone: Select your time zone.
6. User Details: Create a user account. This will be your primary account for logging into the Security Onion system.
7. Installation: The installer will now copy files and install Security Onion. This might take a while, so grab a coffee and be patient.

Once the installation is complete, you'll be prompted to reboot. Go ahead and reboot your system.

Initial Configuration

After the reboot, you'll be greeted with the Security Onion Setup wizard. This is where you configure the network interfaces and set up the monitoring components. This step is super important, so pay close attention!

1. Login: Log in with the user account you created during the installation.
2. Setup Wizard: The Security Onion Setup wizard should start automatically. If it doesn't, you can run it manually by typing sudo so-setup in the terminal.
3. Network Configuration: Choose whether you want to configure a standalone or distributed deployment. For most users, a standalone deployment is sufficient.
   • Standalone: All components are installed on a single machine.
   • Distributed: Components are spread across multiple machines.
4. Network Interfaces: Select the network interface you want to use for management and the interface you want to use for monitoring. Remember, the monitoring interface should be in promiscuous mode.
5. Static or DHCP: Configure the IP address for your management interface. You can use DHCP or set a static IP address.
6. Services Configuration: Choose the services you want to enable. At a minimum, you should enable:
   • Suricata: An intrusion detection and prevention system.
   • Zeek (formerly Bro): A network security monitoring framework.
   • Elasticsearch: A search and analytics engine.
   • Logstash: A data processing pipeline.
   • Kibana: A data visualization dashboard.
   • Strelka: Malware identification and threat hunting.
7. Configuration: The setup wizard will now configure the selected services. This might take a while, so sit tight.

Once the configuration is complete, the setup wizard will provide you with login credentials for the various web interfaces, such as Kibana and CyberChef. Make sure you note these down.

Accessing the Web Interface

Now that Security Onion is installed and configured, let’s access the web interface. Open your favorite web browser and navigate to the IP address of your Security Onion server. You should see the Security Onion console.

Here are some of the key web interfaces:

• Kibana: Use the credentials provided by the setup wizard to log in. Kibana is where you can visualize and analyze the data collected by Security Onion.
• CyberChef: A web-based cyber security "Swiss Army knife" for encoding, decoding, encryption, and more.
• Squert: A web interface for analyzing Suricata alerts.

Updating Security Onion

It’s crucial to keep your Security Onion installation up-to-date with the latest security patches and updates. Run the following commands to update Security Onion:

sudo so-import-pkey
sudo so-allow-community
sudo soup

• so-import-pkey: Imports the Security Onion public key.
• so-allow-community: Enables the Security Onion community repository.
• soup: Updates the system.

This process might take some time, depending on your internet connection and the number of updates available.

Troubleshooting

Sometimes, things don’t go as planned. Here are some common issues and how to troubleshoot them:

• Network Interface Issues: If your monitoring interface isn’t capturing traffic, make sure it’s in promiscuous mode. You can check this using the ifconfig command.
• Service Failures: If any of the services (like Suricata or Zeek) fail to start, check the logs for errors. You can find the logs in /nsm/sensor_data/. Also, checking the status of each service with sudo so-status is beneficial.
• Web Interface Issues: If you can’t access the web interface, make sure the Security Onion services are running and that your firewall isn’t blocking access.

Optimizing Performance

To get the most out of your Security Onion installation, consider these performance optimization tips:

• Hardware Resources: Make sure you have enough CPU, RAM, and storage. Security Onion can be resource-intensive, especially when dealing with a lot of network traffic.
• Disk I/O: Use SSD storage for better performance.
• Network Configuration: Ensure your network interfaces are properly configured and that the monitoring interface is in promiscuous mode.
• Elasticsearch Tuning: Tune Elasticsearch for optimal performance. This might involve adjusting the heap size, shard allocation, and indexing settings.

Conclusion

And there you have it! You’ve successfully installed Security Onion on Ubuntu. Now you can start monitoring your network for threats and analyzing security data. Security Onion is a powerful tool, and with a bit of practice, you’ll be a security ninja in no time. Remember to keep your system updated and to explore the various features and tools that Security Onion offers. Happy hunting!
